- Unisex 27,5" / 50 cm
27,5" / 55 cm
27,5" / 60 cm
golden green matt
TX22 Cross
Shimano Deore XT 12-speed / Bosch Performance Line CX / 625Wh / Disc
Travel-compatible premium e-tourer.
E for extremely impressive! The new expedition series combines the best of different e-bike concepts. Designed as an all-terrain e-tourer with full travel equipment, we have added a full-suspension chassis to the bikes of the TX series. Combined with the new high-end drive of the BOSCH Performance Line CX (4th generation) and a fully integrated 625 Wh battery, the TX22 presents itself as a premium power package for touring cyclists with individual demands for off-road characteristics, as well as for travelling and everyday usability.
Available exclusively in the unisex frame shape shown, the TX22 features an electrifying combination of aesthetic lines and robust, durable components: Shimano Deore XT 12-speed shifter, Shimano 180mm disc brakes, lowerable seat post from EXA, Schwalbe Marathon Plus MTB tyres, integrated frame rack with Racktime system, saddle and handles by Ergon and much more.
Specs
- Frame size
- Unisex 27,5": 50, 55, 60 cm
- Drive Unit
- Bosch Performance Line CX, Gen. 4, 36 V Mid-engine, 250 Watt
- Display
- Nyon, 3,2 inch touch-colour display with remote
- Akku
- Bosch Frame battery fully integrated, 625 Wh, 36 Volt, 16,7 Ah, Down tube
- max load
- 140 kg
- Frame
- Aluminum 6061, Bosch-Interface, 100 mm suspension travel
- Headset
- Acros AZX-212, tapered
- Fork
- Suntour Mobie25 Air, 100 mm travel with lockout-function,
- Rear derailleur
- Shimano Deore XT RD-M8100, 12-speed, Shadow Plus
- Front derailleur
- N.V.
- Brake
- Shimano Deore XT BR-M8100 (front 180 mm / rear 180 mm) Disc brake
- Headlight
- Supernova Mini 2 Pro, with High beam, 160 / 100 LUX including standinglight
